AMD RYZEN 9 7950X3D TRAY PROCESSOR 100-100000908WOF
- AVAILABILITY:
- SKU: 0002502
- CATEGORY: PC ACCESSORIES,PROCESSORS
- Brand: AMD
- Part Number: 100-100000908WOF
- Processor Series: AMD Ryzen
- CPU Socket Type: AMD AM5
3 YEAR WARRANTY
Cores: 16
Threads: 32
Base Clock: 4.2 GHz
Boost Clock: Up to 5.7 GHz
Cache: 144MB L3 Cache (with 3D V-Cache)
TDP: 120W
Architecture: Zen 4 with 3D V-Cache
Socket: AM5
Manufacturing Process: 5nm
Integrated Graphics: No (requires a dedicated GPU)
PCIe Version: PCIe 5.0
| General Specifications | ||
| Name | AMD Ryzen™ 9 7950X3D | |
Family | Ryzen | |
Series | Ryzen 7000 Series | |
Form Factor | Desktops , Boxed Processor | |
Market Segment | Enthusiast Desktop | |
AMD PRO Technologies | No | |
Consumer Use | Yes | |
Regional Availability | Global | |
Former Codename | Raphael AM5 | |
Architecture | Zen 4 | |
# of CPU Cores | 16 | |
Multithreading (SMT) | Yes | |
# of Threads | 32 | |
Max. Boost Clock | Up to 5.7 GHz | |
Base Clock | 4.2 GHz | |
L1 Cache | 1 MB | |
L2 Cache | 16 MB | |
L3 Cache | 128 MB | |
Default TDP | 120W | |
Processor Technology for CPU Cores | TSMC 5nm FinFET | |
Processor Technology for I/O Die | TSMC 6nm FinFET | |
CPU Compute Die (CCD) Size | 71mm² | |
I/O Die (IOD) Size | 122mm² | |
Package Die Count | 3 | |
AMD EXPO™ Memory Overclocking Technology | Yes | |
Precision Boost Overdrive | Yes | |
Curve Optimizer Voltage Offsets | Yes | |
AMD Ryzen™ Master Support | Yes | |
CPU Socket | AM5 | |
Supporting Chipsets | A620 , X670E , X670 , B650E , B650 | |
CPU Boost Technology | Precision Boost 2 | |
Instruction Set | x86-64 | |
Supported Extensions | AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 | |
Thermal Solution (PIB) | Not Included | |
Recommended Cooler | Liquid cooler recommended for optimal performance | |
Max. Operating Temperature (Tjmax) | 89°C | |
Launch Date | 2/28/2023 | |
*OS Support | Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit | |
| Connectivity | ||
| Native USB 3.2 Gen 2 (10Gbps) Ports | 4 | |
| Native USB 3.2 Gen 1 (5Gbps) Ports | 0 | |
Native USB 2.0 (480Mbps) Ports | 1 | |
Native SATA Ports | 0 | |
PCI Express® Version | PCIe® 5.0 | |
Native PCIe® Lanes (Total/Usable) | 28 , 24 | |
Additional Usable PCIe Lanes from Motherboard | X670E | |
12x Gen4 | ||
X670 | ||
12x Gen4 | ||
B650E | ||
8x Gen4 | ||
B650 | ||
8x Gen4 | ||
NVMe Support | Boot , RAID0 , RAID1 , RAID10 | |
System Memory Type | DDR5 | |
Memory Channels | 2 | |
Max. Memory | 128 GB | |
System Memory Subtype | UDIMM | |
Max Memory Speed | 2x1R | |
2x2R | ||
4x1R | ||
4x2R | ||
ECC Support | Yes (Requires mobo support) | |
| Graphics Capabilities | ||
| Graphics Model | AMD Radeon™ Graphics | |
Graphics Core Count | 2 | |
Graphics Frequency | 2200 MHz | |
USB Type-C® DisplayPort™ Alternate Mode | Yes | |
| Key Features | ||
| Supported Technologies | AMD EXPO™ Technology , AMD Ryzen™ Technologies |
