COMMSCOPE CAT 6 KEYSTONE JACK
- AVAILABILITY:
- SKU: 8118
- CATEGORY: NETWORK ACCESSORIES
Rs. 750.00Rs. 500.00
- Category: Category 6 (Cat 6) networks
- Cable Compatibility: unshielded (UTP) cables.
- Termination Method: IDC (Insulation Displacement Connector) for termination
- Wiring Standards: T568A and T568B wiring schemes.
- Mechanical: keystone faceplates and patch panels
- Category: Category 6 (Cat 6) networks
- Cable Compatibility: unshielded (UTP) cables.
- Termination Method: IDC (Insulation Displacement Connector) for termination
- Wiring Standards: T568A and T568B wiring schemes.
- Mechanical: keystone faceplates and patch panels
| Product Series | KJ-Series / UKJ-Series Modular Jack |
| Category Rating | Cat 6 (some variants: Cat 6A) |
| Cable Type | Unshielded (UTP) for many models |
| Conductor Type | Solid and Stranded |
| Termination Type | IDC (Insulation Displacement Connector) |
| Termination Tool | 110 Punchdown tool or JTT tool |
| Mounting | Keystone faceplates and panels |
| Standards / Transmission | ANSI/TIA-568.2-D, ISO/IEC 11801 Class D (or EA for 6A) |
| Contact Material | Beryllium copper (base) |
| Contact Plating | Precious metal / gold or nickel depending on model |
| Maximum Cable Diameter | 5.8 mm |
| Dimensions (H × W × D) | 16.13 mm × ~14–16 mm × 30.48 mm depth |
| Insulation Resistance (min) | 500 MΩ |
| PoE / Power over LAN Support | Some variants support IEEE 802.3bt (Type 4) |
