DAHUA CAT 6 UTP CABLE
- AVAILABILITY:
- SKU: 4230
- CATEGORY: NETWORK ACCESSORIES
🔌 Category 6 (CAT6) Ethernet cable — supports high-speed data transmission up to 1 Gbps with a 250 MHz bandwidth for reliable networking.
🧵 Unshielded Twisted Pair (UTP) design — 4 pairs of twisted conductors for reduced crosstalk and stable signal quality.
🧠 Oxygen-free copper conductors (≈99.97 % purity) — excellent conductivity and minimal signal loss.
📏 23 AWG solid core with conductor diameters ~0.53 mm for robust performance.
🛠 HDPE insulation & PVC jacket — durable protection and flexibility with good tensile strength.
🔥 Flame-retardant & safety compliance — cable meets CPR Eca/UL CM standards for indoor installations.
📡 Support for PoE (Power over Ethernet) — suitable for powering PoE-enabled devices like IP cameras and access points over long distances.
📦 Common length: Typically 305 m (1000 ft) pull-out box for structured cabling projects.
🖥️ Wide compatibility — ideal for LAN networking, CCTV/IP camera installations, routers, switches, and general Ethernet systems.
📊 ANSI/TIA-568 standard compatible — meets industry requirements for CAT6 performance and link quality.
| Brand / Model | Dahua CAT 6 UTP Cable |
| Cable Type | CAT 6 Unshielded Twisted Pair (UTP) |
| Length | 305 m (1000 ft) per roll / carton |
| Conductor Material | Oxygen-free copper (99.97 % purity) |
| Conductor Diameter | ~0.53 mm ± 0.01 mm (24 AWG) |
| Wire Gauge | 24 AWG |
| Pairs / Colors | 4 twisted pairs (Blue/White-Blue, Orange/White-Orange, Green/White-Green, Brown/White-Brown) |
| Insulation Material | HDPE (High-Density Polyethylene) |
| Insulation Thickness | ~0.21 mm |
| Sheath Material | PVC (CE CPR Eca flame-retardant) |
| Cable Diameter | ~6.0mm ± 0.3 mm |
| Characteristic Impedance | 100 Ω ± 15 Ω |
| Bandwidth | 250 MHz |
| Max DC Resistance | ~8.7 Ω/100 m |
| Operating Temperature | –20 °C to +60 °C |
| Storage Temperature | –10 °C to +40 °C |
| Certifications / Standards | ANSI/TIA 568-C.2, CPR Eca |
