DBL DBL-8602 2D DESKTOP BARCODE SCANNER
- AVAILABILITY:
- SKU: 5240
- CATEGORY: BARCODE SCANNER
DBL DBL-8602 2D Desktop Barcode Scanner is a versatile scanning device that quickly reads both 1D and 2D barcodes with high accuracy. Designed for retail, inventory, and point-of-sale environments, it offers fast scanning performance, easy plug-and-play setup, and reliable barcode recognition on paper or screen. A durable and efficient tool to speed up checkout and tracking tasks.
1 YEAR WARRANTY
📸 2D Barcode Reader: Reads both 1D and 2D codes (QR, Data Matrix, PDF417)
🖥️ Desktop Design: Hands-free scanning ideal for counters and POS stations
⚡ Fast & Accurate: Rapid and reliable scanning performance
🔄 Omnidirectional Scanning: Capture codes from any angle without aiming
💡 LED + Beep Feedback: Clear indicators for successful reads
🔌 USB Wired Connection: Easy plug-and-play setup with computers and POS systems
📶 Broad Compatibility: Works with Windows, macOS, and many POS platforms
🛠️ Durable Build: Built for everyday use in retail, offices, and warehouses
📦 Enhanced Efficiency: Speeds up checkout, inventory count, and ticketing
🤲 Comfortable Layout: Stable base for continuous scanning without fatigue
| Model / Type | Syble / XB-8602 2D Hands-Free Desktop Omnidirectional Scanner |
| Image Sensor | 640 × 480 (640x480) CMOS |
| Supported Symbologies | - 1D: Code 39, Code 128, Interleaved 2 of 5, Codabar, GS1-128, EAN-13, UPC-A, etc. - 2D: QR Code, PDF417, DataMatrix, Aztec, MaxiCode, MicroPDF417, etc. |
| Scan Mode | Automatic induction (hands-free) or manual via top button |
| Scan Rate / Speed | Up to 120 FPS (frames per second) according to Syble specs |
| Field of View (FOV) | Horizontal: 44°; Vertical: 34° |
| Recognition / Orientation | 360° rotation, Elevation ±65°, Declination ±65° |
| Scan Range / Depth | 10 mm – 160 mm for EAN-13 (13 mil, PCS=90%) |
| Motion / Speed Tolerance | Up to 3 m/s |
| Interface / Connectivity | - USB (HID / Keyboard) - RS-232 - USB-COM |
| Output / Feedback | - Beep buzzer for successful scan - Indicator light: blue flashing when reading, steady for power |
