GRANDSTREAM GWN7700 5 PORT GIGABIT ETHERNET UNMANAGED NETWORK SWITCH
- AVAILABILITY:
- SKU: 8298
- CATEGORY: NETWORK ACCESSORIES
The Grandstream GWN7700 5-Port Gigabit Ethernet Unmanaged Network Switch is a plug-and-play networking device that adds five high-speed Gigabit LAN ports to your home or small-office network, enabling fast wired connections for computers, printers, gaming devices, and more without any configuration. It features auto-negotiation and auto MDI/MDIX for easy setup, LED link/activity indicators for status at a glance, and a compact, desktop/wall-mountable design — making it a simple, reliable way to expand wired network capacity and support smooth data transfer across devices.
3 YEAR WARRANTY
🔌 5 Gigabit Ethernet Ports: Five 10/100/1000 Mbps RJ-45 ports for fast wired network connections.
⚡ Unmanaged switch: Plug-and-play operation — no configuration or software needed.
💨 High-speed performance: Gigabit data rates for smooth file transfers, streaming, and network traffic.
🌐 Reliable connectivity: Stable wired network for PCs, printers, IP cameras, access points, and other devices.
🛠️ Durable build: Compact metal or robust plastic housing for long-term use.
📶 Auto MDI/MDIX: Eliminates need for crossover cables — auto-detects and adapts.
🔁 Full/half-duplex support: Improves network throughput and efficiency.
🪶 Fanless design: Silent operation — ideal for offices, homes, and quiet workspaces.
📏 Compact form factor: Space-saving design for desktops, shelves, or small network closets.
📊 Energy efficient: Low power consumption with energy-saving features on supported ports.
🖥️ Wide compatibility: Works with all standard Ethernet-enabled devices across brands.
🧰 Easy installation: Simple to install — just connect network cables and power it up.
| Product Name | Grandstream GWN7700 5-Port Gigabit Unmanaged Network Switch |
| Switch Type | Unmanaged Gigabit Ethernet Switch (no configuration required) |
| Gigabit Ports | 5 × 10/100/1000 Mbps RJ45 ports (auto-negotiation) |
| Auto MDI/MDIX | Yes |
| Switching Capacity | 10 Gbps total backplane capacity |
| MAC Address Table | ~2K entries with auto-learning and aging |
| Jumbo Frame Support | Up to 9 KB |
| Advances Features | IEEE 802.3x flow control, 802.1p/DSCP QoS, IGMP snooping/fast-leave, MAC auto-learn/auto-aging |
| Enclosure | Plastic casing |
| Mounting Options | Desktop or wall mount design |
| LED Indicators | Per port Link/Activity, device Power |
| Power Adapter | External 5 V DC / 0.6 A adapter included |
| Max Power Consumption | ~1.7 W (typical) |
| Network Standards | IEEE 802.3i/u/ab (Ethernet, Fast Ethernet, Gigabit), 802.3x, 802.1p QoS |
| Operating Temp. | 0 °C to 40 °C |
| Operating Humidity | 10 % – 90 % non-condensing |
| Dimensions | Approx. 120 × 65 × 24.5 mm (switch body |
| Weight | 0.1 kg |
