HIKVISION DS-2CE16DOT-ITPFS 3.6MM CAMERA Indian

Camera Specifications

• Image Sensor : 2 MP CMOS
• Signal System : PAL/NTSC
• Resolution : 1920 (H) × 1080 (V)
• Frame Rate : TVI: 1080P@30fps, 1080P@25fps, AHD: 1080P@30fps, 1080P@25fps, CVI: 1080P@30fps, 1080P@25fps, CVBS: PAL/NTSC
• Min. illumination : 0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
• Shutter Time PAL: 1/25 s to 1/50, 000 s, NTSC: 1/30 s to 1/50, 000 s
• Lens : 2.8 mm, 3.6 mm, 6 mm Fixed lens
• Field of View : 2.8 mm, horizontal FOV: 106.4°, horizontal  FOV: 57.9°, diagonal FOV: 124.6°, 3.6 mm, horizontal FOV: 79.6°, horizontal FOV: 43.5°, diagonal FOV: 93.7°, 6 mm, horizontal FOV: 51.9°, horizontal FOV: 30°, diagonal FOV: 58.8°
• Lens Mount : M12
• Day & Night : ICR
• WDR (Wide Dynamic Range) : Digital WDR
• Audio : Built-in mic
• Angle Adjustment : Pan: 0 to 360°, Tilt: 0 to 180°, ZŽƚĂƟŽn͗ 0 to 360°

Menu

• Image Mode : STD/HIGH-SAT
• AGC : Yes
• Day/Night Mode : Auto/Color/BW (Black and White)
• White Balance : Auto/Manual
• AE (Auto Exposure) Mode : DWDR/BLC/HLC/Global
• Noise Reducyion : 2D DNR
• Language : English
• Function : Brightness, Sharpness, Mirror, Smart IR

Interface

• Video Output : Switchable TVI/AHD/CVI/CVBS

General

• Operating Conditions : -40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing)
• Power Supply : 12 VDC ± 25%
• Power Consumption : Max. 2.7 W
• Protection Level : IP67
• Material : Plastic
• IR Range : Up to 25 m
• Communication : HIKVISION-C
• Dimensions : 58 mm × 61 mm × 158.6 mm (2.28" × 2.40" × 6.42")
• Weight Approx. : 160 g (0.35 lb.)
