HIKVISION DS-PDMC-EG2-WB WIRELESS MAGNEIC DETECTOR
- AVAILABILITY:
- SKU: 8122
- CATEGORY: ALARM & SECURITY ACCESSORIES
Rs. 9,800.00Rs. 9,200.00
- Detection method: Magnetic contact
- Detection gap: 43 mm max
- Transmission technology: Tri-X Wireless
- Transmission frequency: 433 MHz
- Transmission security: AES-128 encryption
- Transmission range: 1.2 km (free space)
- Power supply: Battery powered (CR123A x 1)
- Operating temperature: 10°C to 55°C
- Storage temperature: -20°C to 60°C
- Dimensions: 22.5 mm x 103 mm x 23.2 mm
- Weight: 59 g
Wireless: No need to run wires, making installation easy.
Magnetic contact: Detects when a door or window is opened.
Tamper protection: Alerts you if the detector is tampered with.
Long battery life: Up to 5 years of battery life.
Small and discreet: Easy to hide.
Specification
Detection Performance
- Detection Method: Opening Contact
- Detection Gap: 43mm Max
Interface
- Alarm Input: Normally Closed;Normally Open;Impulse Count
- Power Switch: Power Up Enrolling
- LED Indicator: Blue (Alarm)
Transmission
- Transmission Technology: Tri-X Wireless
- Transmission Method: Two-Way RF Wireless
- Transmission Frequency: 433MHz
- Transmission Security: AES-128 Encryption
- Transmission Range(Free Space): 1.2Km
- Frequency Hopping: Support
- Enrolling Method: Power up;Remote ID;QR Code
Electrical Characteristics
- Standard Battery Life: Up to 5 years (standby time)
- Power Supply: Battery Powered
- Battery Type: CR123A x 1
- Typical Voltage: 3V
General
- Operation Temperature: -10 °C to 55 °C (14 °F to 131 °F)
- Storage Temperature: -20 °C to 60 °C (-4 °F to 140 °F)
- Operation Humidity: 10% to 90%
- Dimension(WxHxD)
- 24mm × 104mm × 24.4mm
- 13mm × 34.4mm × 11.4mm
- Weight: 59g
- Application Scenario: Indoor
