HIKVISION IDS-7116HQHI-M1/T 16 CHANNEL 1080P MINI ACCUSENSE DVR
- AVAILABILITY:
- SKU: 3909
- CATEGORY: NETWORK ACCESSORIES
The HIKVISION IDS‑7116HQHI‑M1/T is a 16‑channel high‑performance DVR designed for advanced CCTV systems, supporting up to 1080p resolution recording from analog and HD‑TVI cameras. It features AcuSense smart analytics to help filter motion alerts and reduce false alarms, efficient H.265+ compression for longer storage, and network connectivity for remote viewing. With HDMI and VGA outputs for live monitoring and built‑in support for large capacity hard drives, it’s ideal for medium‑to‑large installations in homes, offices, and businesses.
2 YEAR WARRANTY
📹 16 analog video inputs: Supports up to 16 CCTV camera channels (HDTVI/AHD/CVI/CVBS).
🤖 AcuSense Smart Detection: Deep learning‑based Motion Detection 2.0 with human and vehicle classification — reduces false alarms.
🔐 Perimeter protection: Smart perimeter analytics (e.g., line crossing, intrusion) for enhanced security alerts.
📊 Efficient video compression: H.265 Pro+, H.265 Pro, H.265, H.264+ / H.264 — saves storage space and bandwidth.
📺 Recording resolution: Up to 1080p for clear, detailed video capture.
🌐 Hybrid video support: Accepts HD analog + IP cameras, expandable to up to 24 IP cameras (up to 6 MP) with enhanced IP mode.
🖥️ Video outputs: 1× HDMI — up to 4K (3840×2160) @30 Hz, 1× VGA — up to 1080p for flexible monitor connection.
🔊 Audio support: 1× audio input (RCA) + additional audio via coaxial on analog channels, 1× audio output (RCA), Two‑way audio supported via the main input.
📀 Playback: 16‑channel synchronous playback — review multiple camera feeds at once.
💾 Storage: 1× SATA interface, supports up to 10 TB HDD capacity for long‑term recording.
🌐 Network & remote access: Remote monitoring via Hik‑Connect, DDNS, TCP/IP protocols, and mobile/PC apps.
🔄 Dual‑stream support: Allows main high‑resolution stream and sub‑stream for remote viewing with less bandwidth.
🔌 Connectivity: 1× RJ45 10/100/1000 Mbps Ethernet for network access; 2× USB 2.0 for backup/export.
♻️ Energy efficient: Low power consumption (≤ 24 W without HDD).
📏 Compact design: Space‑saving mini 1U DVR chassis — suitable for shelves or small racks.
🌍 Use Cases: Ideal for home, office, retail, business, and industrial security with advanced smart alerting and flexible camera support.
| Product Name | HIKVISION iDS‑7116HQHI‑M1/T 16‑Channel 1080p Mini AcuSense DVR |
| Channels | 16 × Analog camera inputs (BNC) — HDTVI/AHD/CVI/CVBS |
| IP Camera Support | Up to 24 IP channels in enhanced mode (up to 6 MP) |
| Smart Analytics | AcuSense Motion Detection 2.0 (human/vehicle classification), perimeter protection, facial detection |
| Video Compression | H.265 Pro+, H.265 Pro, H.265, H.264+, H.264 |
| Recording Resolution | Up to 1080p/1080p Lite, 4 MP, 5 MP lite, 3K/2K lite, 720p, VGA, etc. |
| Frame Rate (Main Stream) | Varies by resolution: up to 15 fps at 1080p, other modes as supported |
| Video Bitrate Range | 32 Kbps – 6 Mbps |
| Audio Input/Output | 1 × RCA audio input (standard), 1 × RCA audio output, optional audio via coax |
| HDMI Output | 1 × HDMI — up to 4K (3840 × 2160) @ 30 Hz |
| VGA Output | 1 × VGA — up to 1080p |
| Synchronous Playback | 16‑channel simultaneous playback |
| Storage Interface | 1 × SATA HDD interface |
| Max HDD Capacity | Up to 10 TB per HDD |
| Network Interface | 1 × RJ45 10/100/1000 Mbps Ethernet |
| Network Protocols | TCP/IP, PPPoE, DHCP, Hik‑Connect, DNS, DDNS, NTP, UPnP, HTTPS, ONVIF, and more |
| Remote Connections | Up to 128 remote connections |
| USB Ports | 2 × USB 2.0 |
| Power Supply | 12 V DC, 2 A |
| Power Consumption | ≤ 24 W (without HDD) |
| Operating Temp. | ‑10 °C to +55 °C |
| Operating Humidity | 10 % – 90 % (non‑condensing) |
| Dimensions | 285 × 210 × 48 mm |
| Weight | ~1 kg |
