INTEL CORE I5 14400 PROCESSOR BX8071514400
- AVAILABILITY:
- SKU: 0001918
- CATEGORY: PROCESSORS
- Brand : Intel
- CPU Manufacturer : Intel
- CPU Model : Core i5
- CPU Speed : 4.7 GHz
- CPU Socket : PGA LGA1700
3 YEAR WARRANTY
Cores: 6 cores
Threads: 12 threads
Base Clock Speed: 2.50 GHz
Max Turbo Frequency: Up to 4.60 GHz
Cache: 18 MB Intel Smart Cache
TDP (Thermal Design Power): 65W
Socket: LGA 1700
Product Collection | Intel® Core™ i5 Processors (14th gen) | |
Code Name | Products formerly Raptor Lake | |
Vertical Segment | Desktop | |
Processor Number | i5-14400 | |
Lithography | Intel 7 | |
Use Conditions | PC/Client/Tablet | |
Total Cores | 10 | |
# of Performance-cores | 6 | |
# of Efficient-cores | 4 | |
Total Threads | 16 | |
Max Turbo Frequency | 4.7 GHz | |
Performance-core Max Turbo Frequency | 4.7 GHz | |
Efficient-core Max Turbo Frequency | 3.5 GHz | |
Performance-core Base Frequency | 2.5 GHz | |
Efficient-core Base Frequency | 1.8 GHz | |
Cache | 20 MB Intel® Smart Cache | |
Total L2 Cache | 9.5 MB | |
Processor Base Power | 65 W | |
Maximum Turbo Power | 148 W | |
Max Memory Size (dependent on memory type) | 192 GB | |
Memory Types | Up to DDR5 4800 MT/s | |
Up to DDR4 3200 MT/s | ||
Max # of Memory Channels | 2 | |
Max Memory Bandwidth | 76.8 GB/s | |
GPU Name‡ | Intel® UHD Graphics 730 | |
Graphics Max Dynamic Frequency | 1.55 GHz | |
Graphics Output | eDP 1.4b, DP 1.4a, HDMI 2.1 | |
Execution Units | 24 | |
Max Resolution (HDMI)‡ | 4096 x 2160 @ 60Hz | |
Max Resolution (DP)‡ | 7680 x 4320 @ 60Hz | |
Max Resolution (eDP - Integrated Flat Panel)‡ | 5120 x 3200 @ 120Hz | |
DirectX* Support | 12 | |
OpenGL* Support | 4.5 | |
OpenCL* Support | 3 | |
Multi-Format Codec Engines | 1 | |
Intel® Quick Sync Video | Yes | |
Intel® Clear Video HD Technology | Yes | |
# of Displays Supported ‡ | 4 | |
Device ID | 0x4682/0xA782 | |
Direct Media Interface (DMI) Revision | 4 | |
Max # of DMI Lanes | 8 | |
Scalability | 1S Only | |
PCI Express Revision | 5.0 and 4.0 | |
PCI Express Configurations ‡ | Up to 1x16+4, 2x8+4 | |
Max # of PCI Express Lanes | 20 | |
Sockets Supported | FCLGA1700 | |
Max CPU Configuration | 1 | |
Thermal Solution Specification | PCG 2020C | |
TJUNCTION | 100°C | |
Package Size | 45.0 mm x 37.5 mm | |
Intel® Gaussian & Neural Accelerator | 3 | |
Intel® Thread Director | Yes | |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes | |
Intel® Speed Shift Technology | Yes | |
Intel® Turbo Boost Technology ‡ | 2 | |
Intel® Hyper-Threading Technology ‡ | Yes | |
Intel® 64 ‡ | Yes | |
Instruction Set | 64-bit | |
Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 | |
Idle States | Yes | |
Enhanced Intel SpeedStep® Technology | Yes | |
Thermal Monitoring Technologies | Yes | |
Intel® Volume Management Device (VMD) | Yes | |
Intel® Standard Manageability (ISM) ‡ | Yes | |
Intel® Control-Flow Enforcement Technology | Yes | |
Intel® AES New Instructions | Yes | |
Secure Key | Yes | |
Intel® OS Guard | Yes | |
Execute Disable Bit ‡ | Yes | |
Intel® Boot Guard | Yes | |
Mode-based Execute Control (MBEC) | Yes | |
Intel® Virtualization Technology (VT-x) ‡ | Yes | |
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes | |
Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
