INTEL CORE I7 14700K PROCESSOR BX8071514700K
- AVAILABILITY:
- SKU: 0001784
- CATEGORY: PC ACCESSORIES,PROCESSORS
Rs. 123,500.00Rs. 121,000.00
- Brand: INTEL
- Part Number: BX8071514700K
- Processor Series: Intel Core i7CPU
- Socket Type: LGA 1700
3 YEAR WARRANTY
Cores/Threads: 8 cores, 16 threads
Base Clock: 3.4 GHz
Max Turbo Boost Clock: Up to 5.6 GHz
Cache: 24 MB Intel Smart Cache
TDP (Thermal Design Power): 125W (base) / 253W (max turbo power)
Socket: LGA 1700
Architecture: Raptor Lake (14nm process)
Integrated Graphics: Intel UHD Graphics 770 (up to 1.65 GHz)
Unlocked: Yes, for overclocking
| Product Collection | Intel® Core™ i7 Processors (14th gen) | |
| Processor Number | Processor Number i7-14700K | |
| Total Cores | 20 | |
| # of Performance-cores | 8 | |
| # of Efficient-cores | 12 | |
| Total Threads | 28 | |
| Max Turbo Frequency | 5.6 GHz | |
| Intel® Turbo Boost Max Technology 3.0 Frequency ‡ | 5.6 GHz | |
| Performance-core Max Turbo Frequency | 5.5 GHz | |
| Efficient-core Max Turbo Frequency | 4.3 GHz | |
| Performance-core Base Frequency | 3.4 GHz | |
| Efficient-core Base Frequency | 2.5 GHz | |
| Cache | 33 MB Intel® Smart Cache | |
| Max Memory Size (dependent on memory type) | 192 GB | |
| Memory Types | Up to DDR5 5600 MT/s | |
| Up to DDR4 3200 MT/s | ||
| Max # of Memory Channels | 2 | |
| Max Memory Bandwidth | 89.6 GB/s | |
| ECC Memory Supported ‡ | Yes | |
| Processor Graphics ‡ | Intel® UHD Graphics 770 | |
| Graphics Base Frequency | 300 GHz | |
| Graphics Max Dynamic Frequency | 1.6 GHz | |
| Graphics Output | eDP 1.4b, DP 1.4a, HDMI 2.1 | |
| Execution Units | 32 | |
| Max Resolution (HDMI)‡ | 4096 x 2160 @ 60Hz | |
| Max Resolution (DP)‡ | 7680 x 4320 @ 60Hz | |
| Max Resolution (eDP - Integrated Flat Panel)‡ | 5120 x 3200 @ 120Hz | |
| DirectX* Support | 12 | |
| OpenGL* Support | 4.5 | |
| OpenCL* Support | 3 | |
| Multi-Format Codec Engines | 2 | |
| Intel® Quick Sync Video | Yes | |
| Intel® Clear Video HD Technology | Yes | |
| # of Displays Supported ‡ | 4 | |
| Direct Media Interface (DMI) Revision | 4 | |
| Max # of DMI Lanes | 8 | |
| Scalability | 1S Only | |
| PCI Express Revision | 5.0 and 4.0 | |
| PCI Express Configurations ‡ | 20 | |
| Sockets Supported | FCLGA1700 | |
| Max CPU Configuration | 1 | |
| Thermal Solution Specification | PCG 2020A | |
| Intel® Gaussian & Neural Accelerator | 3 | |
| Intel® Thread Director | Yes | |
| Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes | |
| Intel® Speed Shift Technology | Yes | |
| Intel® Turbo Boost Max Technology 3.0 ‡ | Yes | |
| Intel® Turbo Boost Technology ‡ | 2 | |
| Intel® Hyper-Threading Technology ‡ | Yes | |
| Intel® 64 ‡ | Yes | |
| Instruction Set | 64-bit | |
| Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 | |
| Idle States | Yes | |
| Enhanced Intel SpeedStep® Technology | Yes | |
| Thermal Monitoring Technologies | Yes | |
| Intel® Volume Management Device (VMD) | Yes | |
| Intel® Standard Manageability (ISM) ‡ | Yes | |
| Intel® Control-Flow Enforcement Technology | Yes | |
| Intel® AES New Instructions | Yes | |
| Secure Key | Yes | |
| Intel® OS Guard | Yes | |
| Execute Disable Bit ‡ | Yes | |
| Intel® Boot Guard | Yes | |
| Mode-based Execute Control (MBEC) | Yes | |
| Intel® Virtualization Technology (VT-x) ‡ | Yes | |
| Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes | |
| Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
