MSI A520M A PRO MOTHER BOARD
- AVAILABILITY:
- SKU: 2435
- CATEGORY: MOTHERBOARDS
Rs. 25,000.00
Overview
The MSI A520M‑A PRO is a micro‑ATX motherboard designed for AMD AM4 processors. It supports 3rd Gen Ryzen, Ryzen 4000G, and Ryzen 5000 series CPUs, offering dependable performance for budget to mid‑range desktop builds.
3 YEARS WARRANTY
Overview
The MSI A520M‑A PRO is a micro‑ATX motherboard designed for AMD AM4 processors. It supports 3rd Gen Ryzen, Ryzen 4000G, and Ryzen 5000 series CPUs, offering dependable performance for budget to mid‑range desktop builds
| Feature | Specification |
|---|---|
| Socket / Chipset | AM4 / AMD A520 |
| Form Factor | Micro-ATX (23.6 × 20 cm) |
| Memory Support | 2 × DDR4 DIMM, up to 64 GB, 4600 MHz (OC) |
| Expansion Slots | 1 × PCIe 3.0 x16, 1 × PCIe 3.0 x1 |
| Storage | 1 × M.2 (PCIe 3.0 x4/SATA), 4 × SATA III (RAID 0/1/10) |
| Graphics Outputs | 1 × HDMI 2.1, 1 × DVI-D |
| USB Ports | 4 × USB 3.2 Gen 1, 2 × USB 2.0 (rear); internal headers for additional ports |
| Audio | Realtek ALC892/ALC897 7.1-channel HD Audio |
| LAN | Realtek RTL8111H Gigabit Ethernet |
| Internal Headers | 24-pin ATX, 8-pin CPU, fan headers, TPM, front panel, USB 3.2/2.0 |
| Special Features | Core Boost, DDR4 Boost, Audio Boost, M.2 Shield FROZR, EZ Debug LED |
| Compatibility | Supports Ryzen 3000/4000G/5000 series (may require BIOS update) |
| Operating System | Windows 10 64-bit |
| Warranty | 3 years (standard manufacturer warranty) |
