TP LINK TL-SF1005D 5 PORT 100M SWITCH
- AVAILABILITY:
- SKU: 8074
- CATEGORY: NETWORK ACCESSORIES
The TP-Link TL-SF1005D 5 Port 100Mbps Switch is a compact and reliable unmanaged network switch designed to expand wired network connections for homes, offices, and small businesses. Featuring 5 × 10/100Mbps RJ45 ports, it provides fast and stable data transmission for computers, printers, IP cameras, and other network devices. With plug-and-play installation, auto MDI/MDIX support, energy-efficient technology, and a fanless design for silent operation, the TL-SF1005D offers an easy and cost-effective solution for improving network connectivity.
2 YEAR WARRANTY
🌐 5 × 10/100Mbps RJ45 Ports – Provides reliable wired network connections for computers, printers, IP cameras, and other devices.
🚀 Fast Ethernet Performance – Supports up to 100Mbps data transfer speed for smooth everyday networking.
🔌 Plug & Play Design – No configuration or software installation required for quick and easy setup.
⚡ Auto-Negotiation Support – Automatically adjusts connection speed between 10Mbps and 100Mbps devices.
🔄 Auto MDI/MDIX Technology – Eliminates the need for crossover cables during installation.
💾 Store-and-Forward Switching – Ensures accurate and stable data transmission across the network.
🖥️ Compact Desktop Design – Small and lightweight design saves space on your workstation.
🔇 Fanless Operation – Silent performance with no noise from cooling fans.
🌱 Energy Efficient Technology – Automatically reduces power consumption based on network status.
🏠 Ideal for Home & Office Networks – Perfect for internet sharing, file transfer, printers, and small network setups.
🛡️ Reliable TP-Link Quality – Provides stable and dependable network connectivity for everyday use.
| Brand | TP-Link |
| Model | TL-SF1005D |
| Product Type | 5-Port 10/100Mbps Desktop Switch |
| Switch Type | Unmanaged Fast Ethernet Switch |
| Total Ports | 5 × 10/100Mbps RJ45 Ports |
| Port Speed | 10/100Mbps Auto-Negotiation |
| Network Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
| Auto MDI/MDIX | Supported (All Ports) |
| Switching Capacity | 1 Gbps |
| Packet Forwarding Rate | 0.74 Mpps |
| MAC Address Table | 2K Entries |
| Data Transfer Mode | Store-and-Forward |
| Flow Control | IEEE 802.3x Full Duplex Flow Control / Back Pressure Half Duplex |
| Duplex Mode | Full Duplex / Half Duplex |
| Jumbo Frame Support | Up to 2KB |
| LED Indicators | Power, Link/Activity (Per Port) |
| Energy Saving Technology | TP-Link Green Technology |
| Power Consumption | Max. 1.9W |
| Power Supply | External Power Adapter (5V DC / 0.6A) |
| Cooling System | Fanless Design |
| Housing Material | Plastic |
| Installation | Desktop / Wall Mount |
| Plug & Play | Yes (No Configuration Required) |
| Dimensions | 103.5 × 70 × 22 mm |
| Operating Temperature | 0°C to 40°C |
| Storage Temperature | -40°C to 60°C |
| Operating Humidity | 10%–90% RH (Non-Condensing) |
| Storage Humidity | 5%–90% RH (Non-Condensing) |
| Applications | Home Networks, Small Offices, CCTV Networks, Internet Sharing |
