ZEBRONICS ZEB H61M2 DDR3 LGA 1155 SOCKET MOTHERBOARD
- AVAILABILITY:
- SKU: 2434
- CATEGORY: PC ACCESSORIES,MOTHERBOARDS
Rs. 14,600.00Rs. 12,500.00
Suitable For Desktop, Workstation
Intel H61 Express Chipset
Data Rate DDR3
Maximum RAM Capacity 16 GB
Form Factor: Micro-ATX
1 YEAR WARRANTY
- Chipset: Intel H61
- Socket: LGA 1155
- Memory: 2x DDR3 DIMM slots, up to 16GB DDR3 1066/1333/1600 MHz
- Expansion Slots: 1x PCI Express x16, 1x PCI Express x1
- Storage: 4x SATA 2.0 ports
- Audio: Realtek ALC662 6-channel audio
- LAN: Realtek 8106E 10/100 Mbps LAN
- Back Panel I/O: 1x PS/2 keyboard/mouse port, 1x VGA port, 1x HDMI port, 6x USB 2.0 ports, 1x RJ45 LAN port, 3x audio jacks
| Model / Name | ZEBRONICS ZEB‑H61M2 |
| Socket / CPU Compatibility | LGA 1155 - Supports Intel Pentium / Celeron / Core i3 / i5 / i7 (2nd & 3rd Gen) |
| Chipset | Intel H61 (some sources mention H61/H67) |
| Form Factor | Micro-ATX |
| Memory (RAM) | 2 × DDR3 DIMM slots, dual-channel; up to 16 GB; supports DDR3‑1066 / 1333 / 1600 MHz |
| BIOS | AMI BIOS |
| Expansion / Slots | - 1 × PCI Express 2.0 ×16 slot - 1 × PCI Express 2.0 ×1 slot |
| Storage Interfaces | - 3 × SATA II (3 Gbps) port - 1 × M.2 slot (per Zebronics spec) |
| Back‑panel I/O | - 1 × HDMI port - 1 × VGA port - 6 × USB 2.0 ports - 1 × RJ45 Ethernet port - 1 × “3-in-1” audio jack (rear panel) |
| Onboard Connectors | - 24‑pin ATX power connector - 4‑pin ATX 12V power connector - Front-audio header - Front-panel connector - Speaker connector - 2 × Fan connectors - 3 × SATA II ports - 3-pin CMOS header - M.2 slot |
| Audio | 6‑channel HD Audio, Realtek codec (6‑channel) |
| LAN / Network | Realtek 8106E 10/100 Mbps Ethernet |
| Power & Cooling | - 24-pin + 4-pin power connectors - 2 fan headers (CPU + system) |
| Other Features | CMOS reset header (3-pin) |
