EZVIZ CS-X5S R100-8W 8 CHANNEL WIRELESS NVR
- AVAILABILITY:
- SKU: 3772
- CATEGORY: DVR
The EZVIZ CS-X5S R100-8W is an 8-channel wireless network video recorder (NVR) designed for home or small business security systems. It supports up to 8 Wi-Fi cameras at high resolution (up to 3K) and combines wireless and wired connectivity for flexible installation. The NVR features HDMI and VGA outputs for live viewing, efficient H.265/H.264 video compression, and expandable storage with support for up to 8 TB HDD (not included). It also offers multiple recording modes (motion detection, scheduled, manual), playback options, and compatibility with ONVIF-compliant cameras for broader device support.
2 YEAR WARRANTY
📼 8‑Channel Wireless NVR: Supports up to 8 Wi‑Fi cameras for wide‑area surveillance coverage (8 W version)
📺 HDMI & VGA Outputs: View live and recorded video on monitors and TVs in up to 3 K resolution
📺 HDMI & VGA Outputs: View live and recorded video on monitors and TVs in up to 3 K resolution
🧠 Advanced H.265 Compression: Efficient video encoding reduces storage and bandwidth use (up to 50 % vs older formats)
💾 Expandable Storage: Supports one 3.5″ SATA HDD up to 8 TB for long‑term recording (HDD sold separately)
📊 Multi‑Resolution Recording: Handles various resolutions including 3K, 2K+, 1080p and more for flexible setup
📁 Flexible Recording Modes: Manual, motion‑detection, scheduled, and event‑triggered recording options
▶️ Playback Features: Instant, normal, event, tag, and log playback help find footage quickly
🔄 ONVIF & Protocol Support: Compatible with standard protocols for broader camera integration
🌐 Ethernet Port: 10/100 Mbps adaptive interface for network access and remote monitoring
🔌 USB Ports: USB 2.0 for easy backup and file transfer to external drives
⚡ Low Power Consumption: Efficient design with standby power ~ ≤ 8 W
📦 Complete Package: Includes NVR unit, power adapter, mouse, SATA cables, and screws for HDD installation (as applicable)
| Model | CS-X5S-R100-8W |
| Camera support (IPC Access Capability) | Up to 8 wireless or wired IP cameras, each up to 3K |
| Max cameras | 8 channels (8 cameras) |
| Video output | HDMI — 1 channel, up to 2592 × 1944 @ 30 Hz; VGA — 1 channel (same as HDMI output) up to 1920 × 1080 @ 60 Hz |
| Wireless / Network | Dual external antennas; 2.4 GHz Wi-Fi; max wireless range ~100 m |
| Ethernet | 1 × 10/100 Mbps adaptive Ethernet port |
| Video encoding / compression | H.265 and H.264 supported |
| Recording resolution | 3K / 2K+ / 2K / 1080p / UXGA / 720p / VGA / 4CIF / 2CIF / CIF / QCIF |
| Playback / Decode support | Supports simultaneous playback of up to 8 × 3K streams. |
| Recording modes | Manual, motion detection, scheduled, event-triggered recording |
| Backup options | Hard disk backup, remote/internet application backup |
| HDD storage support | 1 × internal SATA port; supports 3.5″ HDD from 1 TB up to 8 TB |
| USB / External interface | 2 × USB 2.0 ports for peripherals/backups |
| Protocols / Compatibility | Compatible with native EZVIZ, plus standard protocol support such as ONVIF (V2.5), and open-protocol cameras including some from Hikvision. |
| Power supply & consumption | DC 12 V / 1.5 A; standby consumption ≤ 8 W |
| Dimensions | 235 × 270 × 44.5 mm (9.25 × 10.6 × 1.75 in) |
