HIKVISION DS-7232HGHI-M2 32 CHANNEL DVR
- AVAILABILITY:
- SKU: 3752
- CATEGORY: DVR
The HIKVISION DS-7232HGHI-M2 32 Channel DVR is a professional-grade digital video recorder designed for large-scale CCTV surveillance installations. Supporting up to 32 camera channels, it delivers reliable high-quality recording, playback, and monitoring for commercial buildings, offices, and large security systems. Featuring advanced H.265+ video compression technology, it optimizes storage efficiency while maintaining excellent image quality. With support for HDTVI/AHD/CVI/CVBS/IP cameras, multiple HDD storage options, HDMI output, and remote access through mobile and PC applications, the DS-7232HGHI-M2 provides a powerful, secure, and flexible surveillance management solution.
2 YEAR WARRANTY
📹 32 Channel Turbo HD DVR – Supports up to 32 analog HD cameras for large-scale surveillance installations
🎥 High-Definition Recording Support – Delivers clear and detailed video recording for security monitoring
🔄 Multi-Signal Camera Support – Compatible with TVI, AHD, CVI, CVBS, and IP cameras for flexible system expansion
🌐 H.265+ Video Compression – Reduces storage requirements and bandwidth usage while maintaining excellent video quality
💾 Dual SATA HDD Support – Supports installation of multiple hard drives for extended recording storage
🔍 High-Resolution Playback – Enables smooth playback and review of recorded surveillance footage
📺 HDMI & VGA Video Output – Provides easy connection to monitors, TVs, and display devices
📡 IP Camera Expansion Support – Allows integration of additional network cameras for system scalability
📱 Remote Monitoring Capability – Enables live viewing and playback through smartphones, tablets, and computers
🎯 Motion Detection & Smart Recording – Helps optimize storage by recording important events
🔐 Secure User Management – Provides reliable access control and surveillance system management
🌙 Supports Advanced Camera Features – Compatible with cameras featuring night vision and enhanced imaging technologies
🏢 Ideal for Large Security Installations – Suitable for factories, warehouses, offices, hotels, schools, and commercial buildings
🧱 Professional 24/7 Surveillance Design – Built for stable and continuous security monitoring
🛡️ Trusted Hikvision Quality – Professional CCTV recording solution from Hikvision
| Brand | Hikvision |
| Model | DS-7232HGHI-M2 |
| Product Type | Turbo HD DVR (Digital Video Recorder) |
| Series | Value Series DVR |
| Channel Capacity | 32 Channel |
| Analog Video Input | 32 × BNC Channels |
| Supported Camera Formats | HDTVI / AHD / HDCVI / CVBS |
| IP Camera Support | Up to 18 IP Channels |
| Maximum IP Camera Resolution | Up to 5MP |
| Recording Resolution | Up to 1080p Lite |
| Video Compression | H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 |
| Video Input Interface | BNC (1.0 Vp-p, 75Ω) |
| HDTVI Input | 1080p25/30, 720p25/30 |
| AHD Input | 1080p25/30, 720p25/30 |
| HDCVI Input | 1080p25/30, 720p25/30 |
| CVBS Input | PAL / NTSC |
| Encoding Capability | Up to 1080p Lite @ 15fps |
| Video Bit Rate | 32 Kbps – 4 Mbps |
| Audio Input | 1 × RCA Audio Input |
| Audio Output | 1 × RCA Audio Output |
| Audio Support | Audio Over Coaxial Cable (Up to 32 Channels) |
| HDMI Output | 1 × HDMI (Up to 1080p) |
| VGA Output | 1 × VGA |
| CVBS Output | 1 × BNC |
| Synchronous Playback | 16 Channels |
| Hard Disk Support | 2 × SATA HDD |
| Maximum Storage Capacity | Up to 10TB per HDD |
| Network Interface | 1 × RJ45 Gigabit Ethernet (10/100/1000 Mbps) |
| Incoming Bandwidth | Up to 128 Mbps |
| Network Protocols | TCP/IP, DHCP, Hik-Connect, DDNS, NTP, SMTP, HTTPS, RTSP |
| Remote Access | Hik-Connect Mobile App & PC Software |
| USB Ports | 2 × USB 2.0 |
| Smart Features | Motion Detection 2.0 |
| AI Detection | Deep Learning Based Human & Vehicle Classification |
| Smart Search | Supported |
| Power Supply | 12V DC |
| Power Consumption | ≤18W (Without HDD) |
| Operating Temperature | -10°C to +55°C |
| Operating Humidity | 10% – 90% |
| Chassis Type | 1U Rack Mount |
| Dimensions | Approx. 380 × 320 × 48 mm |
| Weight | Approx. ≤2.2kg (Without HDD) |
| Usage | Large CCTV Systems, Offices, Shops, Factories, Commercial Security |
