GIGABYTE H81M-DS2 MOTHER BOARD
- AVAILABILITY:
- SKU: 871
- CATEGORY: MOTHERBOARDS
GIGABYTE H81M-DS2 Micro-ATX Motherboard – Intel LGA1150
The GIGABYTE H81M-DS2 is a reliable and compact Micro-ATX motherboard built on the Intel H81 chipset, supporting 4th and 5th generation Intel Core™ processors (LGA1150). Ideal for home, office, or budget-friendly builds, it delivers stable performance with essential features and long-term durability.
This motherboard offers Dual Channel DDR3 memory support, USB 3.0, SATA 6Gb/s, and advanced GIGABYTE technologies such as Ultra Durable™ 4 Plus and UEFI BIOS, ensuring optimized system protection, power efficiency, and performance.
Key Features:
-
Chipset: Intel H81 Express
-
Socket: LGA1150 (Supports 4th & 5th Gen Intel Core™ i7/i5/i3/Pentium/Celeron)
-
Form Factor: Micro-ATX
-
Memory: 2 x DDR3 DIMM slots (up to 16GB)
-
Graphics: Integrated graphics via CPU (1 x VGA port, 1 x DVI-D port)
-
Expansion Slots: 1 x PCIe x16, 2 x PCIe x1
-
Storage Interface: 2 x SATA 6Gb/s + 2 x SATA 3Gb/s
-
USB Ports: USB 3.0 and USB 2.0 ports
-
Audio: Realtek High Definition Audio
-
LAN: Realtek GbE LAN
-
BIOS: UEFI DualBIOS™
-
Ultra Durable™ 4 Plus technology for long life and protection
3 YEARS WARRANTY
GIGABYTE H81M-DS2 Micro-ATX Motherboard – Intel LGA1150
The GIGABYTE H81M-DS2 is a reliable and compact Micro-ATX motherboard built on the Intel H81 chipset, supporting 4th and 5th generation Intel Core™ processors (LGA1150). Ideal for home, office, or budget-friendly builds, it delivers stable performance with essential features and long-term durability.
This motherboard offers Dual Channel DDR3 memory support, USB 3.0, SATA 6Gb/s, and advanced GIGABYTE technologies such as Ultra Durable™ 4 Plus and UEFI BIOS, ensuring optimized system protection, power efficiency, and performance.
✅ Key Features:
-
Chipset: Intel H81 Express
-
Socket: LGA1150 (Supports 4th & 5th Gen Intel Core™ i7/i5/i3/Pentium/Celeron)
-
Form Factor: Micro-ATX
-
Memory: 2 x DDR3 DIMM slots (up to 16GB)
-
Graphics: Integrated graphics via CPU (1 x VGA port, 1 x DVI-D port)
-
Expansion Slots: 1 x PCIe x16, 2 x PCIe x1
-
Storage Interface: 2 x SATA 6Gb/s + 2 x SATA 3Gb/s
-
USB Ports: USB 3.0 and USB 2.0 ports
-
Audio: Realtek High Definition Audio
-
LAN: Realtek GbE LAN
-
BIOS: UEFI DualBIOS™
-
Ultra Durable™ 4 Plus technology for long life and protection
| GIGABYTE H81M-DS2 Motherboard – Specifications | |
|---|---|
| Brand | GIGABYTE |
| Model | H81M-DS2 |
| Form Factor | Micro-ATX |
| Chipset | Intel H81 Express |
| CPU Socket | LGA1150 |
| CPU Support | 4th & 5th Gen Intel Core™ i7/i5/i3, Pentium, Celeron |
| Memory Support | 2 x DDR3 DIMM slots, up to 16GB |
| Memory Type | DDR3 1600/1333 MHz |
| Graphics Output | 1 x VGA port, 1 x DVI-D port (via integrated CPU graphics) |
| Expansion Slots | 1 x PCIe x16, 2 x PCIe x1 |
| Storage Interfaces | 2 x SATA 6Gb/s, 2 x SATA 3Gb/s |
| USB Ports | 2 x USB 3.0, 8 x USB 2.0 |
| Audio | Realtek High Definition Audio |
| LAN | Realtek Gigabit Ethernet |
| BIOS | UEFI DualBIOS™ |
| Special Features | GIGABYTE Ultra Durable™ 4 Plus, Humidity Protection, Power Failure Protection |
| Operating System Support | Windows 7 / 8 / 8.1 / 10 |
