PROLINK CAT 6 UTP CABLE 24AWG
- AVAILABILITY:
- SKU: 949
- CATEGORY: NETWORK ACCESSORIES
The Prolink CAT 6 UTP Cable 24AWG is a high-performance ethernet cable designed for wired network connections, supporting Gigabit (1 Gbps) speeds and reliable data transmission. Its 24-AWG unshielded twisted pair (UTP) construction helps reduce interference and crosstalk, making it ideal for home, office, and data-network installations that demand fast, stable network performance.
🌐 Category 6 (CAT 6) Ethernet cable — supports high-speed network performance
⚡ High data transmission: Supports speeds up to 1Gbps and bandwidth up to 250 MHz
🔌 UTP (Unshielded Twisted Pair): Reduces crosstalk and signal interference
🧵 24AWG pure copper conductors: Ensures stable signal quality and durability
🖥️ Reliable connectivity: Ideal for LAN, WAN, broadband, and structured cabling systems
🏢 Wide application: Suitable for home, office, server rooms, and CCTV networks
🔧 Easy installation: Flexible cable design for smooth routing and termination
📡 Standards compliant: Meets CAT 6 network performance standards
🛡️ Durable outer jacket: Protects cable from wear and environmental stress
🔄 Compatible devices: Works with routers, switches, PCs, IP cameras, patch panels, and wall sockets
| Product Name | PROLINK CAT 6 UTP CABLE 24AWG |
| Category | Category 6 (Cat 6) – supports up to 1 Gbps Gigabit Ethernet and frequencies up to 250 MHz typical for Cat 6 cables. |
| Cable Type | UTP (Unshielded Twisted Pair) — no overall shielding, four twisted pairs. |
| Conductor Gauge | 24 AWG (0.50 ± 0.01 mm) solid bare copper. |
| Conductor Material | Bare solid copper — good conductivity for data transmission. |
| Insulation Material | HDPE (High-Density Polyethylene) — insulation for each conductor. |
| Jacket Material | PVC (Polyvinyl Chloride) — flexible outer sheath. |
| Outer Diameter | Approx. 5.30 mm ± 0.40 mm. |
| Average Insulation Thickness | 0.21 mm (reference). |
| Rip Cord / Filler | Rip cord included for easier stripping; filler helps pair spacing. |
| Insulation Color Code | Standard pairs: White/Blue & Blue, White/Orange & Orange, White/Green & Green, White/Brown & Brown. |
| Bandwidth / Frequency | Up to ~250 MHz (typical Cat6 spec). |
| Transmission Standards | IEEE 802.3af/at (PoE), 10 Base-T, 100 Base-TX, 1000 Base-T Gigabit Ethernet (Cat 6). |
| Use Case / Applications | Wired LAN installations, data networks, routers, switches, PoE devices, IP cameras, VoIP, gaming, etc. |
| Backward Compatibility | Works with lower Ethernet standards (Cat 5e/100 Mbps) as well. |
| Typical Performance | Higher signal-to-noise ratio and reduced crosstalk compared with Cat 5e. |
